TECHNICAL DATA
- Cooling Performance (BTU / h): 12.000
- Thermal Performance (BTU / h): 12.000
- Operation Type: 3D DC Inverter
- Operating Voltage (V / Ph / Hz): 220-240/1/50
- Cooling Energy Class: A ++
- Heating Energy Class: A+/A+++
- SEER: 6.1 W/W
- SCOP: 4.0 W/W
- Noise level (int. / On.): 42/38 dB(A)
- Refrigerant: R-410A
- Refrigirant piping: liquid / gas area: 1/4 "/ 3/8"
- Body Unit Dimensions (PXBxY): 570x570x260 mm
- Panel Unit Dimensions (PxBxY): 647x647x50 mm
- Body Unit Weight: 16/19 kg
- Panel Unit Weight: 2.5/4.5 kg
ADDITIONAL FEATURES
- 360° Air Flow Panel – with the 360° air flow panel, the air can be distributed to every corner of the room.
- Wired Controller – compared with infrared remote controller,wired controller can be fixed on the wall and avoid mislaying. It's mainly used for commercial zone and makes air conditioner control more convenient.
- Built-in Drain Pump – the drain pump can lift the condensing water up to 750mm upmost.
- Low Ambient Cooling – with built-in low ambient kit or special designed PCB, outdoor fan speed can be changed automatically according to condensation temperature. The air conditioner can run cooling operation even when the outdoor ambient temperature down to -15℃.
- Twin Combination – the units can be installed as twin systems: one outdoor unit can be connected with two same indoor units. The indoor units can be combined in any of the different available ratings.
- Self-diagnosis and Auto-protection – once abnormal operation or parts failure happen, the unit will shut off automatically to protect the system. Meanwhile it will indicate protection or error code for fast service.
- Anti-cold Air Function – indoor fan speed is regulated automatically from the lowest grade to the setting grade according to evaporator temperature when the unit just starts heating operation. This function can prevent cold air blowing out to avoid discomfort to the users.
- Auto Restart Function – if the air conditioner breaks off unexpectedly due to the power cut, it will restart with the previous setting mode automatically when the power resume.
- Turbo Mode – by pressing the turbo button on the remote controller, the unit will enter turbo mode with ultra-high speed and reach the set temperature more quickly. After running 20 minutes in turbo mode, the indoor fan will automatically recover the preset speed.
- Sleep Mode – this function enables the air conditioner to automatically increase (in cooling mode) or decrease (in heating mode) 1°C per hour for the first two hours, then hold steady for the next five hours. After that it will switch off the unit. This maintains comfort during the night as well as saving energy.
- Timer
- Fireproof E-box
