Forward Centrifugal fan YWFF140
Detailed Product Description
—Material:
- Housing: galvanized sheet steel
- Impeller: galvanized sheet steel
- Rotor: Coated in black plastic
—Diameter of Impeller: 140mm
—Direction of rotation: Clockwise, seen on rotor
—Type of protection: IP54
—Insulation class: B or F
—Mounting position: Shaft horizontal or rotor on bottom; rotor on top on request(Any)
—Condensate discharges: Rotor-side
—Mode of operation: Continuous operation (S1)
—Bearings: Maintenance- free ball bearings
—Motor protection: TOP wired internally
—Cable exit: variable, lateral
—Product conforming to standard: CE Approval
—Approval: UL Approval, CCC Certificate
| performance parameters |
|
|
|
|
|
|
|
|
|
| Model |
Voltage V |
Frequency Hz |
Current A |
Input Power |
Speed WRPM |
Capacitor μF |
Netweight KG |
Noise dB(A) |
Max Air Flow m³/h |
Curve |
|
| YWF-F4E-140 |
230 |
50/60 |
0.27/0.30 |
60/65 |
1400/1550 |
3 |
3 |
52/55 |
285/300 |
2,4 |
|
| YWF-F2E-140 |
230 |
50/60 |
0.62/0.80 |
165/195 |
2550/2450 |
5 |
3,5 |
66/64 |
480/470 |
1,3 |
|
