| AC forward Centrifugal fan YWFF180 |
|
|
|
|
|
|
|
| —Material: Housing: galvanized sheet steel |
|
|
|
|
|
|
|
| Impeller: galvanized sheet steel |
|
|
|
|
|
|
| Rotor: Coated in black plastic |
|
|
|
|
|
|
| —Diameter of Impeller: 180mm |
|
|
|
|
|
|
|
|
| —Direction of rotation: Clockwise, seen on rotor |
|
|
|
|
|
|
| —Type of protection: IP54 |
|
|
|
|
|
|
|
|
| —Insulation class: B or F |
|
|
|
|
|
|
|
|
| —Mounting position: Shaft horizontal or rotor on bottom; rotor on top on request(Any) |
|
|
|
| —Condensate discharges: Rotor-side |
|
|
|
|
|
|
|
| —Mode of operation: Continuous operation (S1) |
|
|
|
|
|
|
| —Bearings: Maintenance- free ball bearings |
|
|
|
|
|
|
|
| —Motor protection: Design with thermal overload protector |
|
|
|
|
|
| —Cable exit: variable, lateral |
|
|
|
|
|
|
|
|
| —Product conforming to standard: CE Approval |
|
|
|
|
|
|
| —Approval: UL Approval, CCC Certificate |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
| 1.performance parameters |
|
|
|
|
|
|
|
|
| Model |
Voltage V |
Frequency Hz |
Current A |
Input Power W |
Speed RPM |
Capacitor μF |
Netweight KG |
Noise dB(A) |
Max Air Flow m³/h |
Curve |
| YWF-F4E-180-1 |
230 |
50/60 |
0.38/0.60 |
90/120 |
1330/1350 |
3 |
5,2 |
54/55 |
970/1000 |
1,2 |
| YWF-F4E-180-2 |
230 |
50/60 |
0.65/0.83 |
140/188 |
1350/1420 |
4 |
5 |
55/56 |
1080/1150 |
3,4 |
